Texecom Odyssey X-B Grade 3 Sounder with Integral Backlight Backplate
£36.77 (inc VAT: £44.12)
Summary
The Odyssey X3 is a high-performance external sounder designed to illuminate your logo, elevate your brand, and deliver the highest quality security. This innovative product brings a modern twist to external sounders, providing unparalleled performance and extensive features that benefit both installers and end users.
Features
- Wired, wireless & dummy versions available
- White comfort LEDs for enhanced visibility
- A host of installer-friendly features
- Designed to comply with EN50131-4 standards
Specifications
- Supply Voltage : 12-16 VDC (13.7 Nominal)
- Current Drain (Typical at 13.7VDC) : Quiescent: 18mA +40mA (Backlit Version)
- Strobe : 100mA
- Sounder SAB LC SCB : 445mA 230mA 70mA
- Standby Battery : Type: NiMh Stack
- Voltage : 7.2VDC (Nominal)
- Capacity : 250mAh
- Flash Tube : 1Ws Xenon
- Comfort LEDs Brightness : 100mcd (Typical)
- Flash Rate (Tamper Secure) : 1Hz Alternating (Typical)
- Wireless Frequency : 868.0MHz – 868.6MHz
- Volume (SAB Mode at 13.7 VDC) : 115dB(A)
- Acoustic Output : Varying Sound Output
- Cut-Off Time : 15 Minutes
- Waterproof Coating : Conformal
- Operating Temperature : -25°C to +55°C
- Storage Temperature : -25°C to +60°C
Downloads
- Datasheet (Adobe PDF)
