Fike Sita 803-0022 Addressable Monitored Output Unit
£69.34 (inc VAT: £83.21)
Summary
The 803-0022 is an addressable monitored output unit mounted with a standard double gang box. Provides a single 24v DC monitored output suitable for the control of conventional sounders and visual alarm devices.
This connects directly to a Fike Sita addressable loop and requires a 24V DC to drive the connected warning devices.
Features
- Monitored output unit to Fike Sita addressable systems
- Provides a single 24V DC monitored output suitable for the control of conventional sounders/beacons
- Supplied with double gang back box
Specifications
- Operating Temperature : -10°C to +50°C
- Voltage Range : 32 to 42v DC
- PSU Input Voltage : 24 to 32v DC
- LED Indication :
- Output Activated : LED on
- Contact Rating :
- Output : Max load 2.5A
- Fuses :
- Fuse 1 : 3A Anti surge 20mm (eg. Bussman S505-3.15A)
- Dimensions :
- Overall : 146x87x41mm
- Back Box : 146x87x32mm
Downloads
- Manual (Adobe PDF)
Additional information
| Weight | 0.25 kg |
|---|---|
| Device Type | |
| System Type | |
| Protocol |
