Serage 32 Channel PoE 4xHDD 4K NVR
Summary
The Serage SR9032NP/4 is a 32-channel network video recorder designed for large-scale IP camera installations requiring high performance and intelligent video analytics. With 16 built-in 802.3at/af PoE ports, the unit provides straightforward plug-and-play connectivity for compatible IP cameras, eliminating the need for a separate PoE switch for the majority of deployments.
Built around Serage’s AI engine, the SR9032NP/4 supports a comprehensive range of detection capabilities including facial recognition, automatic number plate recognition (ANPR), people counting, crowd density analysis, pedestrian and vehicle detection, and in-pick detection. These functions make the recorder well suited to retail, commercial, and public-space environments where actionable intelligence is as important as raw recording capability.
The SR9032NP/4 is fully NDAA-compliant, confirming its suitability for government, enterprise, and federally funded projects. Recording resolutions up to 12MP are supported across all 32 channels, with H.265+ compression ensuring efficient storage use across four SATA hard drive bays. Remote access is available via the Serage AI mobile application for iOS and Android, with push notifications keeping operators informed in real time.
Features
- 32-channel network video recorder supporting resolutions up to 12MP (4K)
- 16 built-in PoE ports (802.3at/af) for direct plug-and-play camera connection
- NDAA-compliant — suitable for government, enterprise, and federally funded installations
- AI features include facial recognition, ANPR, people counting, crowd density, pedestrian and vehicle detection, and in-pick detection
- 320 Mbps incoming and outgoing bandwidth
- H.265 / H.265+ / H.264 / H.264+ video compression for efficient storage
- Frame rates up to 480fps at 1080P and 2MP; up to 30fps at 12MP
- Dual HDMI outputs (HDMI 1 up to 4K/EDID; HDMI 2 up to 1080P async) and one VGA output
- 4 SATA HDD bays, each supporting up to 12TB capacity
- 2 RJ45 Ethernet ports (100/1000 Base-T) for network connectivity
- USB 2.0 (front), USB 3.0 and USB 2.0 (rear) for local backup and peripherals
- 16 alarm inputs and 1 alarm output
- 1 RS485 port and 1 e-SATA port
- Audio input and output via RCA connectors
- Motion detection with adjustable sensitivity (levels 1–8)
- Event alerts via beep, email, and mobile app push notification
- Playback at fast forward/rewind (2×, 4×, 8×, 16×) and slow forward (1/2×, 1/4×, 1/8×, 1/16×)
- Serage AI mobile application for iOS, Android, and Windows remote access
- Web browser support: IE10/11, Safari v12.1+, Firefox v52+, Chrome v57+, Edge v79+
- OSD available in 20+ languages including English, French, Spanish, German, Arabic, Japanese, and more
- Factory reset via 10-second button press
- ATX 280W power supply; 12W power consumption (excluding HDD)
- Operating temperature range: -10°C to +50°C
FAQs
How many cameras can the SR9032NP/4 support?
The SR9032NP/4 supports up to 32 IP cameras simultaneously. Of these, up to 16 cameras can be connected directly to the unit’s built-in PoE ports, with additional cameras connected via the network using the two onboard RJ45 Ethernet ports.
What resolution does the SR9032NP/4 record at?
The recorder supports resolutions from 720p through to 12MP (4K), making it compatible with a wide range of Serage and third-party IP cameras. Recording at 12MP is supported at up to 30fps per channel.
What AI detection features are available?
The SR9032NP/4 supports a range of AI-driven analytics including facial recognition, automatic number plate recognition (ANPR), people counting, crowd density monitoring, pedestrian and vehicle detection, and in-pick (object removal/placement) detection. Some AI functions require a compatible AI-capable camera.
Is the SR9032NP/4 NDAA-compliant?
Yes. The SR9032NP/4 is fully compliant with the National Defense Authorization Act (NDAA), confirming it is safe for use by government agencies, enterprises, and organisations receiving federal funding.
How much storage does the SR9032NP/4 support?
The unit features four SATA hard drive bays, each supporting drives of up to 12TB, giving a potential maximum raw storage capacity of 48TB. HDDs are not included and must be purchased separately.
Can I access the recorder remotely?
Yes. Remote access is available via the Serage AI mobile application, which is compatible with iOS, Android, and Windows devices. Push notifications can be configured to alert users to motion detection events and other alarms in real time. Web browser access is also supported.
What video outputs does the SR9032NP/4 have?
The recorder provides two HDMI outputs and one VGA output. HDMI 1 supports resolutions up to 3840×2160 (4K) via EDID negotiation; HDMI 2 supports up to 1920×1080 as an asynchronous spot output. The VGA output supports resolutions up to 1920×1080.
Which video compression formats are supported?
The SR9032NP/4 supports H.265, H.265+, H.264, and H.264+ compression. H.265+ provides the most efficient compression, helping to reduce storage consumption and bandwidth requirements without compromising image quality.
Specifications
- Model: SR9032NP/4
- Channels: 32
- Supported Resolutions: 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / 720p
- Video Compression: H.265+ / H.265 / H.264+ / H.264
- Audio Compression: G.711A / G.711U
- Frame Rate: 12MP: 30fps; 8MP: 120fps; 4MP: 240fps; 2MP: 480fps; 1080P: 480fps
- Inputs Bandwidth: 320 Mbps
- Outputs Bandwidth: 320 Mbps
- AI: Yes — facial recognition, ANPR, people counting, crowd density, pedestrian and vehicle detection, in-pick detection
- PoE Ports: 16 × RJ45, 802.3at/af
- Ethernet Ports: 2 × RJ45 100/1000 Base-T
- HDMI 1 Output: 1 × up to 3840×2160 (EDID)
- HDMI 2 Output: 1 × up to 1920×1080, async
- VGA Output: 1 × up to 1920×1080
- USB Ports: USB 2.0 × 1 (front); USB 3.0 × 1 + USB 2.0 × 1 (rear)
- HDD Bays: 4 × SATA, each up to 12TB
- Audio In: 1 × RCA
- Audio Out: 1 × RCA
- Alarm Input/Output: 16 in / 1 out
- RS485: 1
- E-SATA: 1
- Event Notifications: Beep, email, mobile app push notification
- Mobile Application: Serage AI (iOS, Android, Windows)
- Web Browser Support: IE10/11, Safari v12.1+, Firefox v52+, Chrome v57+, Edge v79+
- OSD Languages: English, French, Spanish, Portuguese, German, Italian, Greek, Danish, Finnish, Russian, Hebrew, Turkish, Bulgarian, Arabic, Korean, Japanese, Thai, Hindi, Romanian, Dutch, Polish
- Dimensions (W × D × H): 378 × 326 × 66mm
- Power Supply: ATX 280W
- Power Consumption: 12W (excluding HDD)
- Operating Temperature: -10°C to +50°C
- Humidity: Less than 90% RH
- NDAA Compliant: Yes
Downloads
- Datasheet (Adobe PDF)
